蛍光セキュリティ顔料

※ 仕様・納期・価格等については弊社までお問い合わせください。

※ また, このHPに紹介されている製品以外で取り扱い可能な製品もございます。詳細は弊社までお問い合わせください。仕様は予告なく変更される場合があります。

紫外線蛍光セキュリティ顔料

UV Fluorescent Pigments

蛍光セキュリティ材料は, 自然光下では蛍光を発せず, UV-A, UV-BまたはUV-C領域の非可視光により励起され, 可視光(蛍光)を発します。
Luminochem社の特殊発光製品は, 蛍光効果を簡単に実装でき, 優れた発光強度を備え, 濃青色(藍色, 紺色)から深紅(真紅, 暗紅色, 深緋)までの色を表示します。
Fluorescent security materials can be excited by non-visible light in the UV‑A, UV‑B or UV‑C region and emit visible light, while showing no color in daylight. Luminochem’s special luminescent products have an easy to implement fluorescent effect with excellent emission intensity, displaying colors from ice blue to deep red.

LUWH1 仕様へ移動	LUPA1 仕様へ移動	LUHK2 仕様へ移動
LU0012 仕様へ移動	LURK1 仕様へ移動	LURK14 仕様へ移動
LUGB 仕様へ移動	LUCG2 仕様へ移動	LUPCS 仕様へ移動
LUPCZ2 仕様へ移動	LUPCZ 仕様へ移動	LUABS1 仕様へ移動
LUEG 仕様へ移動	LUTZ1 仕様へ移動	LUCYG 仕様へ移動
LUNSAB2 仕様へ移動	LUYG1 仕様に移動	LURZ4 仕様へ移動
LUWY4 仕様へ移動	LUWY1/A 仕様へ移動	LUABU1 仕様へ移動
LUNAR2 仕様へ移動	LUSI05 仕様へ移動	LUNAR1 仕様へ移動
LURED19 仕様へ移動	LLUREDBN11 仕様へ移動	LURED20 仕様へ移動
LUREDBN2 仕様へ移動	LUREDP8 仕様へ移動	LUCR 仕様へ移動
LUTTIS3 仕様へ移動	LUREDCP2 仕様へ移動	REDBNS1 仕様へ移動

Particle size, D90 (μm): max. 4 μm	Optimal Excitation: UV-A
Chemical fastness: 4.4	Thermal stability up to (°C): 200
Light fastness 2
Daylight color White	UV color Brightwhite UV-A

Particle size, D90 (μm): max. 2 μm	Optimal Excitation: UV-A
Delivery form: Powder	Thermal stability up to (°C): 250
Light fastness 1
Daylight color White	UV color Purple UV-A

Particle size, D90 (μm): max. 3 μm	Optimal Excitation: UV-A
Chemical fastness: 4.9	Thermal stability up to (°C): 310
Light fastness 2
Daylight color White	UV color Blue UV-A

Particle size, D90 (μm): ≤ 35	Optimal Excitation: UV-A
Chemical fastness: 4.9	Thermal stability up to (°C): 196
Light fastness 2
Daylight color Light yellow	UV color Blue UV-A

Particle size, D90 (μm): max. 3	Optimal Excitation: UV-A
Chemical fastness: 3.2	Thermal stability up to (°C): 300
Light fastness 2
Daylight color Light yellow	UV color Blue UV-A

Particle size, D90 (μm): max. 3	Optimal Excitation: UV-A
Chemical fastness: 4.2	Thermal stability up to (°C): 200
Light fastness 2
Daylight color White	UV color Blue UV-A

Particle size, D90 (μm): max. 5	Optimal Excitation: UV-A
Chemical fastness: 4.3	Thermal stability up to (°C): 100
Light fastness 5
Daylight color light yellow	UV color green-blue UV-A

Particle size, D90 (μm): max. 3	Optimal Excitation: UV-A
Chemical fastness: 3.8	Thermal stability up to (°C): 250
Light fastness 4
Daylight color Pale yellow	UV color Green UV-A

Particle size, D90 (μm): ≤ 2	Optimal Excitation: UV-A
Chemical fastness: 4.4	Thermal stability up to (°C): N/A
Light fastness: 4-5	Visual effect: UV-A (365 nm) --> (520 nm)
Daylight color White	UV color Green-yellow

Particle size, D90 (μm): お問い合わせください	Optimal Excitation: UV-B, UV-C
Chemical fastness: お問い合わせください	Thermal stability up to (°C): お問い合わせください
Light fastness 7
Daylight color White	UV color Red UV-B, UV-C
概要 LUREDBNS1 は, UVB(303nm)および UVC(254nm)を励起光として, 鮮やかな赤色の蛍光を発色します。UVA(365nm)には反応しないため, 安全性を高めた特殊な用途に最適です。 LUREDBNS1 is a special pigment in our portfolio that stands out due to its unique fluorescence characteristics. LUREDBNS1 is specifically designed to be UVB (303 nm) and UVC (254 nm) excitable, delivering a vibrant red fluorescence. Remarkably, it remains absolutely dull under UVA (365 nm), making it an ideal choice for secure and specialized applications. 特徴励起光はUVBおよびUVC: LUREDBNS1 は, UVBを励起光とするため, プラスチックカードやラミネート製品に適しています。UVAの下では不発光: LUREDBNS1 は, UVB 光でのみ蛍光を発します。秘匿性を有する印刷のセキュリティ高めます。強い赤色蛍光を発色: UVBの下で鮮やかな蛍光を視認できます。 UVB and UVC Excitability: LUREDBNS1 can be efficiently excited in the UVB range, making it perfect for use on plastic cards and laminated products. Invisible Under UVA: Fluorescence can only be revealed using UVB light, providing an added layer of security for hidden prints. Strong Red Fluorescence: The resulting image is bright and eye-catching, ensuring clear visibility under UVB illumination.

Particle size, D90 (μm): max. 2	Optimal Excitation: UV-A
Chemical fastness: 4.2	Thermal stability up to (°C): 300
Light fastness 5
Daylight color White	UV color Green UV-A

Particle size, D90 (μm): max. 3	Optimal Excitation: UV-A
Chemical fastness: 3.9	Thermal stability up to (°C): 230
Light fastness 3
Daylight color White	UV color Green-yellow UV-A

Particle size, D90 (μm):	Optimal Excitation: UV-A
Chemical fastness: 3.3	Thermal stability up to (°C): 190
Light fastness 4
Daylight color White	UV color Yellow-green UV-A

Particle size, D90 (μm): 2	Optimal Excitation: UV-A
Chemical fastness: 3.2	Thermal stability up to (°C): 190
Light fastness 4
Daylight color White	UV color Yellow-green UV-A

Particle size, D90 (μm): 0.8-1.6	Optimal Excitation: UV-A
Chemical fastness: 3.2	Thermal stability up to (°C): 190
Daylight color White	UV color yellowish green UV-A

Particle size, D90 (μm):	Optimal Excitation: UV-A
Chemical fastness: 2.9	Thermal stability up to (°C): 150
Light fastness 3
Daylight color White	UV color Green-yellow UV-A

Particle size, D90 (μm): 3	Optimal Excitation: UV-A
Chemical fastness: 4.9	Thermal stability up to (°C): 270
Light fastness 4
Daylight color White	UV color Yellow UV-A

Particle size, D90 (μm): 2.5	Optimal Excitation: UV-A
Chemical fastness: 4.8	Thermal stability up to (°C): 290
Light fastness 4
Daylight color White	UV color Yellow UV-A

Particle size, D90 (μm): 4	Optimal Excitation: UV-A
Chemical fastness: 4.2	Thermal stability up to (°C): 185
Light fastness 4
Daylight color White	UV color Orange UV-A

Particle size, D90 (μm): 4	Optimal Excitation: UV-A
Chemical fastness: 4.7	Thermal stability up to (°C): 248
Light fastness 4
Daylight color White	UV color Orange UV-A

蛍光セキュリティ顔料

関連ページ

Particle size, D90 (μm): 3	Optimal Excitation: UV-A
Chemical fastness: 4	Thermal stability up to (°C): 240
Light fastness 5
Daylight color White	UV color Red UV-A

Particle size, D90 (μm): 3	Optimal Excitation: UV-A
Chemical fastness: 3.7	Thermal stability up to (°C): 145
Light fastness 2
Daylight color White	UV color Red UV-A

Particle size, D90 (μm):	Optimal Excitation: UV-A
Chemical fastness: N/A	Thermal stability up to (°C): 282
Light fastness 1
Daylight color White	UV color Red UV-A

Particle size, D90 (μm): 3	Optimal Excitation: UV-C
Chemical fastness: 3.6	Thermal stability up to (°C): 410
Light fastness 5
Daylight color White	UV color Green-yellow UV-C

Particle size, D90 (μm): 4	Optimal Excitation: UV-C
Chemical fastness: 2.8	Thermal stability up to (°C): 110
Light fastness 5
Daylight color White	UV color Red UV-C
